| Processor |
133
MHz Pentium (Higher speed CPU¡¯s may be used, depending on
supplier
availability,
even though the RU Spec does not require higher speeds) |
| Frequency
Range |
1
kHz to 5 MHz, nominal |
Precision
Parallelepiped
Sample Holder |
•Two
piezoelectric transducers (one driver and one receiver) with a
temperature
range of 0¡ÆC to 95¡ÆC.
•The
transducers are mounted to provide precision x-y-z geometry
adjustment
for optimizing individual resonant amplitude and minimizing
deformation of
parallelepiped sample.
•A
clear, environmental cover is provided to protect from external
noise during
measurements and dust when not in use.
•Cabling
to computer/tranceiver included. |
| Internal
Modem |
33.6
or 56.6 kps |
| Hard
Drive |
1.6
Gigabyte (A higher storage capacity hard drive may be used,
depending on
supplier
availability of the 1.6 Gigabyte drives.
The RI-1000 does not require a hard
drive
with storage greater than 1.6 Gigabytes.) |
| Floppy
Drive |
3.5
inch standard 1.4 Megabyte |
| Dimensions |
17"
x 17.5" x 7" plus monitor |
| Power
Requirements |
100-120
volts or 200-240 volts, 50/60 Hz, 300 watts with 15 inch monitor |
Operating
Temperature
Range |
0¡ÆC
to 50¡ÆC |
Storage
Temperature
Range |
0¡ÆC
to 63¡ÆC |
Relative
Humidity
(Operating and Storage) |
5%
to 95% with the ambient temperature above the dew point.
(Condensation
is to be avoided.
Although the RU Spec may be stored at 0¡ÆC,
immediate
removal of the instrument from an environment at this temperature
to an
environment
at a higher temperature may cause unwanted condensation, even
though
none of the nominal specifications have been violated.
If such storage
conditions
occur, the User should wait sufficient time before turning the
instrument
on
so as to allow any possible condensation to evaporate.) |
| Compliance |
The
RU Spec complies with the European EMC Directive and has received
CE
certification. |
